Understanding Moon Phases

Explanation of Lunar Phases

Before we describe the phases of the Moon, let’s describe what they’re not. Some people mistakenly believe the phases come from Earth’s shadow cast on the Moon. Others think that the Moon changes shape due to clouds. These are common misconceptions, but they’re not true. Instead, the Moon’s phase depends only on its position relative to Earth and the Sun.
TheMoon doesn’t make its own light, it just reflects the Sun’s light as all the planets do. The Sun always illuminates one half of the Moon. Since the Moon is tidally locked, we always see the same side from Earth, but there’s no permanent “dark side of the Moon.” The Sun lights up different sides of the Moon as it orbits around Earth — it’s the fraction of the Moon from which we see reflected sunlight that determines the lunar phase. The lunar phase or phase of the Moon is the shape of the directly sunlit portion of the Moon as viewed from Earth.
Thelunar phases gradually change over the period of a synodic month (about 29.53 days), as the orbital positions of the Moon around Earth and of Earth around the Sun shift. The Moon's rotation is tidally locked by Earth's gravity; therefore, most of the same lunar side always faces Earth. This near side is variously sunlit, depending on the position of the Moon in its orbit. Thus, the sunlit portion of this face can vary from 0% (at new moon) to 100% (at full moon). The lunar terminator is the boundary between the illuminated and darkened hemispheres. Each of the four "intermediate" lunar phases is around 7.4 days, but this varies slightly due to the elliptical shape of the Moon's orbit. Aside from some craters near the lunar poles, such as Shoemaker, all parts of the Moon see around 14.77 days of daylight, followed by 14.77 days of "night". The side of the Moon facing away from Earth is sometimes called the "dark side of the Moon", although that is a misnomer.

Moon Phase Diagram

As shown in this diagram, the New Moon occurs when the moon is positioned between the earth and sun. The three objects are in approximate alignment. The entire illuminated portion of the moon is on the back side of the moon, the half that we cannot see.
At a Full Moon, the earth, moon, and sun are in approximate alignment, just as the new moon, but the moon is on the opposite side of the earth, so the entire sunlit part of the moon is facing us. The shadowed portion is entirely hidden from view.
The First Quarter and Last Quarter (aso called Third Quarter) moons (both often called a "half moon"), happen when the moon is at a 90 degree angle with respect to the earth and sun. So we are seeing exactly half of the moon illuminated and half in shadow.
Once you understand those four key moon phases, the phases between should be fairly easy to visualize, as the illuminated portion gradually transitions between them. An easy way to remember and understand those "between" lunar phase names is by breaking out and defining 4 words: crescent, gibbous, waxing, and waning. The word crescent refers to the phases where the moon is less than half illuminated. The word gibbous refers to phases where the moon is more than half illuminated. Waxing essentially means "growing" or expanding in illumination, and waning means "shrinking" or decreasing in illumination.
Thus you can simply combine the two words to create the phase name, as follows: After the new moon, the sunlit portion is increasing, but less than half, so it is waxing crescent. After the first quarter, the sunlit portion is still increasing, but now it is more than half, so it is waxing gibbous. After the full moon (maximum illumination), the light continually decreases. So the waning gibbous phase occurs next. Following the third quarter is the waning crescent, which wanes until the light is completely gone a new moon.

Lunar Perigee and Apogee

The Moon's orbit around Earth is elliptical, with one side closer to Earth than the other. As a result, the distance between the Moon and Earth varies throughout the month and the year. On average, the distance is about 382,900 kilometers (238,000 miles) from the Moon's center to the center of Earth. The point on the Moon's orbit closest to Earth is called the perigee and the point farthest away is the apogee.
The Moon's phase and the date of its approach to its perigee or apogee are not synced. When a Full Moon or New Moon occurs close to the Moon's perigee, it is known as a Supermoon. On the other hand, when a Full Moon or New Moon occurs close to the Moon's apogee, it is known as a Micromoon. The Moon passes through the 2 extreme points–or apsides–perigee and apogee about once a month.
The time it takes for the Moon to travel from perigee to perigee, is called the anomalistic month, and takes around 27.55455 days. This is not to be confused with the synodic month, which lasts a little longer, and is the time it takes the Moon to orbit once around Earth, from New Moon through all the Moon phases to the next New Moon. The Supermoon on November 14, 2016, was the closest a Full Moon has been to Earth since January 26, 1948. The next time a Full Moon is even closer to Earth will be on November 25, 2034 (dates based on UTC time). How can Full Moon be in the daytime? Moonrise is the best time to view the Moon, weather permitting, of course. At this time, illusion mixes with reality to make a low-hanging Moon that looks unnaturally large when compared to foreground objects.

Orientation by Latitude

In the Northern Hemisphere, if the left (east) side of the Moon is dark, then the bright part is thickening, and the Moon is described as waxing (shifting toward full moon). If the right (west) side of the Moon is dark, then the bright part is thinning, and the Moon is described as waning (past full and shifting toward new moon). Assuming that the viewer is in the Northern Hemisphere, the right side of the Moon is the part that is always waxing. (That is, if the right side is dark, the Moon is becoming darker; if the right side is lit, the Moon is getting brighter.)
In the Southern Hemisphere, the Moon is observed from a perspective inverted, or rotated 180°, to that of the Northern and to all of the images in this article, so that the opposite sides appear to wax or wane. Closer to the Equator, the lunar terminator will appear horizontal during the morning and evening. Since the above descriptions of the lunar phases only apply at middle or high latitudes, observers moving towards the tropics from northern or southern latitudes will see the Moon rotated anti-clockwise or clockwise with respect to the images in this article.
The lunar crescent can open upward or downward, with the "horns" of the crescent pointing up or down, respectively. When the Sun appears above the Moon in the sky, the crescent opens downward; when the Moon is above the Sun, the crescent opens upward. The crescent Moon is most clearly and brightly visible when the Sun is below the horizon, which implies that the Moon must be above the Sun, and the crescent must open upward. This is therefore the orientation in which the crescent Moon is most often seen from the tropics. The waxing and waning crescents look very similar. The waxing crescent appears in the western sky in the evening, and the waning crescent in the eastern sky in the morning.

Blue Moon

The term "Blue Moon" has traditionally, in the Maine Farmer's Almanac, referred to an "extra" full moon, where a year which normally has 12 full moons has 13 instead. The "blue moon" reference is applied to the third full moon in a season with four full moons, thus correcting the timing of the last month of a season that would have otherwise been expected too early. This happens every two to three years (seven times in the Metonic cycle of 19 years). The March 1946 issue of Sky & Telescope misinterpreted the traditional definition, which led to the modern colloquial misunderstanding that a blue moon is a second full moon in a single solar calendar month with no seasonal link.
Owing to the rarity of a blue moon, the term "blue moon" is used colloquially to mean a rare event, as in the phrase "once in a blue moon". One lunation (an average lunar cycle) is 29.53 days. There are about 365.24 days in a tropical year. Therefore, about 12.37 lunations (365.24 days divided by 29.53 days) occur in a tropical year. In the widely used Gregorian calendar, there are 12 months (the word month is derived from moon) in a year, and normally there is one full moon each month. Each calendar year contains roughly 11 days more than the number of days in 12 lunar cycles. The extra days accumulate, so every two or three years (seven times in the 19-year Metonic cycle), there is an extra full moon. The extra full moon necessarily falls in one of the four seasons, giving that season four full moons instead of the usual three, and, hence, a blue moon.
The frequency of a blue moon can be calculated as follows. It is the period of time it would take for an extra synodic orbit of the moon to occur in a year. Given that a year is approximately 365.2425 days and a synodic orbit is 29.5309 days, then there are about 12.368 synodic months in a year. For this to add up to another full month would take 1/0.368 years. Thus it would take about 2.716 years, or 2 years, 8 months and 18 days for another blue moon to occur.

Formation

The Moon formed 4.51 billion years ago, some 60 million years after the origin of the Solar System. Several forming mechanisms have been proposed,including the fission of the Moon from Earth's crust through centrifugal force (which would require too great an initial spin of Earth), the gravitational capture of a pre-formed Moon (which would require an unfeasibly extended atmosphere of Earth to dissipate the energy of the passing Moon), and the co-formation of Earth and the Moon together in the primordial accretion disk (which does not explain the depletion of metals in the Moon). These hypotheses also cannot account for the high angular momentum of the Earth–Moon system.
Theprevailing hypothesis is that the Earth–Moon system formed after an impact of a Mars-sized body (named Theia) with the proto-Earth (giant impact). The impact blasted material into Earth's orbit and then the material accreted and formed the Moon. The Moon's far side has a crust that is 50 km (31 mi) thicker than that of the near side. This is thought to be because the Moon fused from two different bodies. This hypothesis, although not perfect, perhaps best explains the evidence.
Giant impacts are thought to have been common in the early Solar System. Computer simulations of giant impacts have produced results that are consistent with the mass of the lunar core and the angular momentum of the Earth–Moon system. These simulations also show that most of the Moon derived from the impactor, rather than the proto-Earth. However, more recent simulations suggest a larger fraction of the Moon derived from the proto-Earth. Other bodies of the inner Solar System such as Mars and Vesta have, according to meteorites from them, very different oxygen and tungsten isotopic compositions compared to Earth. However, Earth and the Moon have nearly identical isotopic compositions. The isotopic equalization of the Earth-Moon system might be explained by the post-impact mixing of the vaporized material that formed the two, although this is debated.
The impact released a lot of energy and then the released material re-accreted into the Earth–Moon system. This would have melted the outer shell of Earth, and thus formed a magma ocean. Similarly, the newly formed Moon would also have been affected and had its own lunar magma ocean; its depth is estimated from about 500 km (300 miles) to 1,737 km (1,079 miles). While the giant impact hypothesis might explain many lines of evidence, some questions are still unresolved, most of which involve the Moon's composition.

Humans on the Moon

A Moon landing is the arrival of a spacecraft on the surface of the Moon. This includes both crewed and robotic missions. The first human-made object to touch the Moon was the Soviet Union's Luna 2, on 13 September 1959. The United States' Apollo 11 was the first crewed mission to land on the Moon, on 20 July 1969. There were six crewed U.S. landings between 1969 and 1972, and numerous uncrewed landings, with no soft landings happening between 22 August 1976 and 14 December 2013. The United States is the only country to have successfully conducted crewed missions to the Moon, with the last departing the lunar surface in December 1972. All soft landings took place on the near side of the Moon until 3 January 2019, when the Chinese Chang'e 4 spacecraft made the first landing on the far side of the Moon. After the unsuccessful attempt by Luna 1 to land on the Moon in 1959, the Soviet Union performed the first hard Moon landing – "hard" meaning the spacecraft intentionally crashes into the Moon – later that same year with the Luna 2 spacecraft, a feat the U.S. duplicated in 1962 with Ranger 4. Since then, twelve Soviet and U.S. spacecraft have used braking rockets (retrorockets) to make soft landings and perform scientific operations on the lunar surface, between 1966 and 1976. In 1966 the USSR accomplished the first soft landings and took the first pictures from the lunar surface during the Luna 9 and Luna 13 missions. The U.S. followed with five uncrewed Surveyor soft landings.
The Soviet Union achieved the first uncrewed lunar soil sample return with the Luna 16 probe on 24 September 1970. This was followed by Luna 20 and Luna 24 in 1972 and 1976, respectively. Following the failure at launch in 1969 of the first Lunokhod, Luna E-8 No.201, the Luna 17 and Luna 21 were successful uncrewed lunar rover missions in 1970 and 1973. Many missions were failures at launch. In addition, several uncrewed landing missions achieved the Lunar surface but were unsuccessful, including: Luna 15, Luna 18, and Luna 23 all crashed on landing; and the U.S. Surveyor 4 lost all radio contact only moments before its landing. More recently, other nations have crashed spacecraft on the surface of the Moon at speeds of around 8,000 kilometres per hour (5,000 mph), often at precise, planned locations. These have generally been end-of-life lunar orbiters that, because of system degradations, could no longer overcome perturbations from lunar mass concentrations ("masscons") to maintain their orbit. Japan's lunar orbiter Hiten impacted the Moon's surface on 10 April 1993. The European Space Agency performed a controlled crash impact with their orbiter SMART-1 on 3 September 2006.
A total of twelve men have landed on the Moon. This was accomplished with two US pilot-astronauts flying a Lunar Module on each of six NASA missions across a 41-month period starting 20 July 1969, with Neil Armstrong and Buzz Aldrin on Apollo 11, and ending on 14 December 1972 with Gene Cernan and Jack Schmitt on Apollo 17. Cernan was the last man to step off the lunar surface. All Apollo lunar missions had a third crew member who remained on board the command module. The last three missions included a drivable lunar rover, the Lunar Roving Vehicle, for increased mobility.

Moon Landing Gallery
